TRACO Power TEN 30-3622UIR Isolated 30W 9-75Vin +12Vout 1250mA, -12Vout 1250mA 2x1 housing

Width: 25.4 mm (1 in)

Height: 10.2 mm (0.402 in)

Length: 50.8 mm (2 in)

Industry: Industrial

Dimensions: 50.8 mm x 25.4 mm x 10.2 mm

Application: Industrial

Unit Weight: 35 g

Output Power: 30 W

Input Voltage: 9 VDC to 75 VDC

Mounting Style: Through Hole

Isolation Voltage: 3 kV

Number of Outputs: 2 Output

Input Voltage - Max: 75 V

Input Voltage - Min: 9 V

Input Voltage, Nominal: 36 V

Output Current-Channel 1: 1.25 A

Output Current-Channel 2: 1.25 A

Output Voltage-Channel 1: 12 V

Output Voltage-Channel 2: - 12 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
