Toshiba TC7PCI3212MT,LF Multiplexers/Demultiplexers 2 Differential Ch 2:1 mux/demux SPDT

Bandwidth: 11.5 GHz

Supply Type: Single Supply

Unit Weight: 17 mg

Configuration: 2 x 2:1

On Time - Max: 50 us

Mounting Style: SMD/SMT

Off Time - Max: 6.5 ns

Number of Channels: 2 Channel

Off Isolation - Typ: - 20 dB

On Resistance - Max: 13.5 Ohms

Supply Current - Max: 500 uA

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 3 V

Switch Voltage - Max: 3.6 V

Pd - Power Dissipation: 500 mW (1/2 W)

Propagation Delay Time: 0.1 ns

Operating Supply Voltage: 3.3 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
