Travels:
X-Axis: 10 in. (254 mm)
Y-Axis: 6.25 in. (159 mm)
Z-Axis: 10 in. (254 mm)
Spindle
Spindle Power: 0.75 hp (0.56 kW)
Maximum Speed: 10,000 RPM
Transmission: Poly-V Belt
Spindle Taper: R8
Threading: Thread Mill
Maximum Feed Rate
X- and Y-Axis: 135 IPM (3.43 m/min)
Z-Axis: 110 IPM (2.79 m/min)
Axis Motor: Stepper Driven
Power
Power Required: Single-Phase 115 Vac, 50/60 Hz, 15A breaker
Machine Specifications
Table Size: 18 in. × 6.3 in. (457 mm × 160 mm)
Table Slots: 3/8 in. (9.5 mm)(three slots)
Spindle Note to Table Max Clearance: 12 in. (305 mm)
Spindle Centerline to Machine Column: 6.5 in. (165 mm)
Machine Size: 42 in. × 36 in. (1.1m × 0.8 m)
Overall System Height: 70 in. (1.8 m)
Typical System Weight: 600 lb. (272 kg)
