Withstanding Voltage Test
Output Voltage:
- AC: 0.05 —5.00kV ± (2% reading+5digits) , (50Hz、60Hz optional)
- DC: 0.05 —6.00kV ± (2% reading+5digits)
- Voltage Adjustment Rate: ≤ (1% - 5V)（rated power）
Current Test Range:
- AC: 0.000mA – 20.00mA ±(2% reading+2digits)
- DC: 0uA –10.00mA ±(2% reading+2digits)
- Discharge Function: Discharge after test ends（DCW）
Insulation Resistance Test
Output Voltage: 0.10kV – 1.00kV ±(2%reading+2V)
Resistance Test Range: 1MΩ– 9999MΩ
Resistance Test Accuracy:
- 500V- 1000V: 1MΩ– 1000MΩ ±(5%reading+2digits) ;1000MΩ–9999MΩ ±(10%reading+2digits)
- 100V- 500V: 1MΩ– 1000MΩ ±(10%reading+2digits)
Discharge Function: Discharge after test ends
Arc Detection
Measurement Range:
- AC: 1 – 9 levels （factory default 5）（20mA、18mA、16mA、14mA、12mA、10mA、7.7mA、5.5mA、2.8mA respectively）
- DC: 1 – 9 levels
General Specification:
Memory: 5 groups
Voltage Rising Time: 0.1s – 999.9s
Test Time Setting（AC/DC）: 0.2s – 999.9s
Waiting Time（IR）: 0.2s – 999.9s
Time Accuracy: ±(1%+0.1s)
Dimension（W×H×D）: 280mm×89mm×428mm/10kg
Interface:
Standard: HANDLER, RS232, USBDRV(PC interface), USBHOST(USB port)
Scan Interface: 8 channels
