Test Pin: 64
Passive Component:
- Signal Source: 50Hz — 300kHz, 1Vrms
- Capacitance Test: 1pF — 1000μF
- DCR: 5mΩ — 10MΩ
Conductance/Transient Conduct: 5mΩ — 950Ω
DC Withstand Voltage: Voltage: 5V — 1000V, Current: 1μA — 11.5mA.
AC Withstand Voltage: Voltage: 50V — 750V, Current: 0.01mA — 11.5mA.
ARC Detection: Level 8
Insulation Resistance: Voltage: 5V — 1000V, Resistance: 1MΩ — 5GΩ.
Open/Short Circuit: 1kΩ — 50kΩ
Diode Test: Forward voltage drop: 0 — 7.5V, LED lighting time setting, Reverse leakage current.
Test Speed:
- Transient Open/short: 4ms
- Transient Open: 5us - 2ms
