Display: 10.1 Inches TFT LCD Display 1280×RGB×800, Touch Screen
AC Parameter: Cp/Cs、Lp/Ls、Rp/Rs、|Z|、|Y|、R、X、G、B、θ、D、Q、VAC、IAC
DC Parameter: VDC、IDC、DCR
Test Frequency
+ Range: 10 Hz - 80 MHz
+ Resolution: 1mHz
+ Relative frequency tolerance: ≤±0.0007%
Test Level
+ AC Voltage: 5mV—2Vrms
+ Resolution: 1mV
+ AC Current: 50uA—20mArms
+ Resolution: 10uA
DC Bias:
+ Voltage: 0V-±40V
+ Resolution: 1mV
+ Current: 0mA-±100mA
+ Resolution: 40μA
Test Display Range: E means 1,000,000,000,000,000,000
Cs, Cp: -9.99999EF -+9.99999EF
Ls, Lp: -9.99999EH -+9.99999EH
D: -9.99999E -+9.99999E
Q: -9.99999E -+9.99999E
R, Rs, Rp, X, Z: -9.99999EΩ -+9.99999EΩ
G, B, Y: -9.99999ES -+9.99999ES
Vdc: -9999V -+9999V
Idc: -9999mA -+9999mA
θr: -999999rad -+999999rad
θd: -180.0deg -+180.0deg
Δ%: -999999% -+999999%
Test terminal configuration: Four Terminal Pair
Output impedance: 25Ω / 100Ω
Input Voltage: 100-120VAC/198-242VAC Option, 47-63Hz
Power consumption: Max 150VA
Measurement（WxHxD）: 428x220x325
Weight: 14.5kg
