Test Parameters: Cp-D, Cp-Q, Cp-Rp, Cp-G, Cs-D, Cs-Q, Cs-Rs
Test Signal Frequency:
- Permitted frequency: 100Hz,120Hz, 1kHz,10kHz,100kHz,1MHz,1MHz±1%,1MHz±2%
- Accuracy: ±0.02%
Level:
- Range: 0.1V-1V
- Resolution: 0.01V
- Accuracy: ±5%
Output Mode: Continuous or synchronous
Signal Source Delay:
- Range 0-1s
- Resolution 0.1ms
Signal Level Compensation:
- 100/120Hz: 220μF, 470μF, 1mF range
- 1kHz: 22μF, 47μF, 100μF range
Output impedance
- 100 Hz/ 120Hz:
SLC OFF ( ≥ 220μF range): 1.5 Ω
SLC ON ( ≥ 220μF range): 0.3 Ω
2.2μF - 100μF range: 0.3 Ω
10 nF - 1μF range: 10 Ω
- 1kHz:
SLC OFF ( ≥ 22μF range): 1.5 Ω
SLC ON ( ≥ 22μF range): 0.3 Ω
220 nF - 10μF range: 0.3 Ω
100 pF - 100 nF range: 10 Ω
- 10kHz/100kHz: 10 Ω
- 1MHz: 10 Ω
Test signal frequency range:
- 100Hz/120Hz: 10 nF, 22 nF, 47 nF, 100 nF, 220 nF, 470 nF, 1μF, 2.2μF, 4.7μF, 10μF, 22μF, 47μF, 100μF, 220μF, 470μF, 1 mF
- 1k Hz: 100 pF, 220 pF, 470 pF, 1 Nf, 2.2 nF, 4.7 nF, 10 nF, 22 nF, 47 nF, 100 nF, 220 nF ,470 nF, 1μF, 2.2μF, 4.7μF, 10μF, 22μF, 47μF, 100μF
- 10k Hz: 100 pF, 220 pF, 470 pF, 1 nF, 2.2 nF, 4.7 nF, 10 nF, 22 nF, 47 nF, 100 nF, 220 nF, 470 nF, 1μF, 2.2μF , 4.7μF, 10μF
- 100k Hz 10 pF, 22 pF, 47 pF, 100 pF, 220 pF , 470 pF, 1 nF, 2.2 nF, 4.7 nF, 10 nF, 22 nF, 47 nF, 100 nF
- 1MHz 1 pF, 2.2 pF, 4.7 pF, 10 pF, 22 pF, 47 pF, 100 pF, 220 pF, 470 pF, 1 nF
Measurement display range:
- Cs, Cp: ±1.000000 aF ~ 999.9999 EF
- D: ±0.000001 ~ 9.999999
- Q: ±0.01 ~ 99999.99
- Rs, Rp: ±1.000000 aΩ ~ 999.9999 EΩ
- G: ±1.000000 aS ~ 999.9999 ES
- Δ%: ±0.0001 % ~ 999.9999 %
Basic measurement accuracy: C:0.07%, D:0.0005
Temperature, humidity, height (operating environment): 0 ℃ - 45 ℃, 15% - 85% RH (≤40℃, non-condensing), 0 - 2000m
Power supply:
- voltage: 90VAC - 264VAC
- frequency: 47Hz - 63Hz
- power Max.150VA
Temperature, humidity, height (Storage environment): -20 ℃ - 70 ℃，0 - 90% RH (≤65℃，non-condensing)，0 - 4572m
