Inner Size (W*D*H mm）: 225L（600*500*750）
Outer Size(Excluding rotrusions)W*D*Hmm: 800*1553*1950
Outer Size(Including protrusions)W*D*Hmm: 896*1737*1950
Temperature Range: -40~150℃
Heating Rate: （+20~150℃）≥2℃/min
Cooling Rate: （+20~-40℃）≥1℃/min
Temperature Uniformity: ≤2℃
Temperature Deviation: ≤±2℃
Temperature Fluctuation: ≤±0.5℃
Temperature Accuracy: 0.1℃
Maximum Heat Dissipation: 5900W
Refrigerant: R404A
Drainage pipe specifications: DN10mm
Weight: 480kg
Inner Chamber material: SUS304 δ1.0mm
Outer Chamber material: SPCC+Coatingδ1.5mm
Appearance: RAL9006
Insulation materials: Glass wool+phenolic foam board
Noise: ≤69d(B) Test at a height of 1.2m and 1m directly ahead
Window Size: W360*H480mm
Cooling Type: Air cooling (forward air, rear air outlet)
Test Hole: Φ100mm*2（ 1 on left and right Center）
Sample holder specifications: 20kg/PCS ,total Two PCS
Voltage: AC380V±10% 50Hz±10%
Max Power(KW): 4KW
Maximum Current（A）: 14A
Leakage Switch（A）: 25A
