- General Specification
+ Frequency: 26GHz
+ Beam Angle: 8° (4 inch Cone antenna & PTFE Sealing antenna); 18°(2inch Cone antenna & PTFE Sealing antenna); 25°(1inch Rod antenna)
- Measurement:
+ MAX range: 30 m
+ Accuracy: Cone & PTFE Sealing ±2mm; Rod ±3mm
+ Repeatability: ±1mm
+ Interval: 1s
+ Tracking rate: 2m / sec max
- Display: 5 digits LCD / 4 keys-menu-driven Level, Distance, Volume (Flow), Current, Signal strength selectable
- Power Supply Signal Output:
+ Power Supply (Loop-Powered): DC10.5V ～ 36V (In case of Ex, the voltage is rated separately.)
+ Signal Output: 4 ～ 20mA + HART
+ Alarm: Hold, 22mA or 3.6mA selectable
- Mechanical Specification
+ Tank Pressure: 1.5MPa
+ IP Class: IP66, NEMA4X
Features
±2mm High Accuracy
Advanced Echo Processing
Rapid Tracking
Flow & Volume Calculation
Wide Lin-Up for various applications
Explosion - proof
Intrinsically safe
Target Market
Petro - chemical
Fine - chemical
Pharmaceutical
Food
General industrial
Water distribution
Factory effluent
[Cone]
[PTFE sealing]
