Source voltage: AC110V/220V, 50/60HZ
Power: 10-50W
Dimension (L*W*H): 290mm(L)*270mm(W)*100mm(H)
Weight: 4kg
Voltage test (V1)
Range: 0—5 V, Resolution: 0.001V, Accuracy: 0.2% + 3
Range: 0—10 V, Resolution: 0.01V, Accuracy: 0.3% + 5
Charging (CHA): Range: 50—2000mAh, Resolution: 1mA, Accuracy: 2% + 3
Discharging: Range: 50—200mAh Resolution: 1mA Accuracy: 1% + 5
Over discharging current (OVC): Range: 0—20 A Resolution: 0.01A Accuracy: 2% + 3
Internal Impedance (IMP): Range: 0—999 mΩ Resolution: 1mΩ Accuracy: ±1mΩ
Short-circuit protection (SPT): Range: 0—99.9 mS Resolution: 0.1mS Accuracy: 2% + 3
Thermistor (R1/R2): Range: 0—999.9 kΩ Resolution: 0.1kΩ Accuracy: 2% + 3
Capacity: Range: 0—9999 mAH Resolution: 1mAH Accuracy: 3%
