TOB TOB-BE-IS Battery Internal Short-Circuit Integrated Testing Machine (0℃~100℃)

1.Temperature control box technical specifications

Temperature range: 0℃~+100℃

Analytical precision: 0.01℃

Temperature fluctuation: ±0.5℃

Temperature uniformity: ±2.0℃

Temperature rising rate: Average 3℃/min（from 0℃ to 100℃、Nonlinear load）

Temperature falling rate: Average 1℃/min（from 1000℃ to 0℃、Nonlinear load）

Within the box size: W600*H750*D500MM

Within the box material: Mirror stainless steel plate,the bottom reinforcement

Carton size: W1500*H1750*D1000MM

Carton Material: Stainless steel or cold rolled steel paint treatment

2.Shield prick test specifications

Max load: 200kg

Force value resolution: 1/10000

Force accuracy: ≤0.5%

Force value magnification: 1/1000

Displacement resolution: 7-speed automatic switch

Displacement accuracy: ≤0.5%

Shield thorn: 10*10MM

Speed Range: 0.01~20MM/S

Effective stroke: 150MM（Without holder）

Test largest plane: 300*300MM(Customized)

3.Voltage data collection

Voltage data collection range: 0~20V，Acquisition frequency 100HZ/S

Voltage resolution: 1MV

Stop voltage range can be set: 0~20V
