Source voltage: AC220V, Single phase. Customized according country request
Power: 10KW
Compressed air: 0.6MPa
Output: 6ppm, according to vacuum holding and sealing time
Vacuum flow: 350 M3/hour
Suitable battery size: Length 130-285mm, Width 100-170mm, Thickness 8-11mm
Structure configuration
Trough body 3SET
Battery rotating mechanism 1SET
Automatic feeding mechanism 1SET
Weight before filling 1SET
Into the jig transfer institution 1SET
Pour institutions without electric pump 1SET
Vacuum holding box 3SET
Vacuum pre-sealing 1SET
Discharge transfer institution 1SET
Weight after filling 1SET
Automatic discharging device 1SET
Automatic receiving institutions 2SET
With PLC, Touch screen,
Driving motor 2SET
Project control system 1SET
CAM drive motor 2SET
Vacuum holding box: 1-99s can be set, with -95kpa vacuum degree
Vacuum pre-sealing machine: Sealing stamp width : 8mm
Sealing head length : 300mm
Sealing TEM: Max 260℃, adjustable
Sealing Head parallelism : ±0.02mm
Vacuum degree: -90KPa
Dimension (L*W*H): 8000*1500*2400mm
Weight: 4000kg
