Max. Pressure (T): 100
Max. Stroke (mm): 24
Crimping Range (mm²): 240 – 1000
Crimping Dies (mm²): 240, 630
Crimp Pattern: Hexagonal type
Gross Weight (kg): 50
Packing Size (mm): 230 × 320 × 450
Characteristics:
Double-acting, 100 Tons
●Sturdy construction for safe working.
●Simple design for easy maintenance.
●Ram retracts hydraulically, the retracting time is 1/3 of spring return.
●Removable die cap design helps operator an easy insertion and removable of the connector.
●Functional handles for easy carrying and repositioning.
●Requires an external double acting hydraulic pump. with rated oil pressure of 700 bar.
●Designed as a portable tool for installing compression sleeves and terminals for transmission construction and maintenance work.
●Comes delivered in sturdy wooden box.
Crimping Range:
Copper sleeve up to 76 mm O.D.
Aluminum sleeve up to 76 mm O.D.
Steel sleeve up to 50 mm O.D.
