Amplifier Type: Digital (Limiting)
Bit Rate (Maximum): 12.5 Gb/s
Internal Laser:
- Laser Type: C-Band Tunable
- Wavelength Range(a): 1527.6 - 1565.5 nm
- Output Power (Typ.): 13.5 dBm
External Laser(b):
- Wavelength Range(c): 1250 nm - 1610 nm
- Optical Input Power: 20 dBm (Max); 22 dBm (Absolute Max)
Power Calibration Points: 1310 nm, 1550 nm, and 1590 nm
Optical Extinction Ratio: 13 dB (Typical Maximum)
Electrical Return Loss (d): -10 dB (Any RF Port, Typical)
Modulator Type: Phase
Optical Insertion Loss (Typical)(e): 4.5 dB (1550 nm). 6.5 dB (1310 nm)
Internal Optical Fiber: PM Ports: PM PANDA Fiber. SM Port: SMF-28-Compatible Fiber
Fiber Connectors: FC/PC, 2.0 mm Narrow Key
(a) C-band and L-band lasers are tunable in 50 GHz steps. An 850 nm fixed-wavelength laser can be substituted upon request: contact Thorlabs’ Tech Support.
(b) User-Supplied
(c) Using the modulator at another wavelength (e.g. visible light) may cause an increase in insertion loss and will void the warranty.
(d) To the -3 dB Bandwidth
(e) Laser IN to Optical OUT.
