Model: FGX-2005
Manufacturer:Texio
Warranty: 12 months
Arbitrary Functions
Sample Rate 20 MSa/s
Repetition Rate 10MHz
Waveform Length 4k points
Amplitude Resolution 10 bits
Non-Volatile Memory 4k points
Frequency Characteristics
Range Sine 0.1Hz~5MHz 0.1Hz~12MHz
Square 0.1Hz~5MHz 0.1Hz~12MHz
Triangle, Ramp 1MHz
Resolution 0.1Hz
Accuracy Stability ±20 ppm
Aging ±1 ppm, per 1 year
Tolerance ≤ 1 mHz
Output Characteristics
Amplitude Range 1 mVpp to 10 Vpp (into 50Ω)
2 mVpp to 20 Vpp (open-circuit)
Accuracy ± 2% of setting ±1 mVpp
(at 1 kHz/Sin Wave/50Ω/Offset:0V)
Resolution 1 mV or 3 digits
Flatness ± 1% (0.1dB) ≤100kHz
± 3% (0.3 dB) ≤5MHz
± 5% (0.4 dB) ≤12MHz
(sine wave relative to 1 kHz/50Ω)
Units Vpp, Vrms, dBm
Offset Range ±5 Vpk ac +dc (50Ω)
±10Vpk ac +dc (Open circuit)
Accuracy 2% of setting + 5 mV+ 0.5% of amplitude
Waveform
Output
Impedance 50Ω typical (fixed)
> 300kΩ (output disabled)
Attenuator —
Protection Short-circuit protected
Overload relay automatically disables main
output
SYNC
Output
Level TTL-compatible into >1kΩ
Impedance 50Ω nominal
Fan Out —
Rise of Fall Time ≤ 25ns
