Polarity: Positive
Output Type: Adjustable
Mounting Style: SMD/SMT
Output Current: 3 A
Dropout Voltage: 270 mV
Line Regulation: 0.03 mV/V
Load Regulation: 0.04 mV/A
Number of Outputs: 1 Output
Reference Voltage: 800 mV
Input Voltage - Max: 6.5 V
Input Voltage - Min: 1.1 V
Output Voltage Range: 500 mV to 5.15 V
Dropout Voltage - Max: 450 mV
Pd - Power Dissipation: 900 mW
Ib - Input Bias Current: 2.4 mA
Voltage Regulation Accuracy: 0.75 %
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
PSRR / Ripple Rejection - Typ: 42 dB
