Width: 3.5 mm
Height: 1.6 mm
Length: 6.5 mm
Polarity: Positive
Output Type: Fixed
Unit Weight: 120 mg
Mounting Style: SMD/SMT
Output Current: 1 A
Output Voltage: 1.6 V
Dropout Voltage: 170 mV
Line Regulation: 0.15 %/V
Load Regulation: 0.25 %/A
Number of Outputs: 1 Output
Reference Voltage: 1.263 V
Moisture Sensitive: Yes
Input Voltage - Max: 6 V
Input Voltage - Min: 1.8 V
Ib - Input Bias Current: 75 uA
Operating Supply Current: 75 uA
Voltage Regulation Accuracy: 2 %
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
