Features: EasyScale 1-Wire Interface, Enable/Shutdown, OVP, PWM Control, Soft Start, Thermal Shutdown
Topology: Boost
Output Type: Boost
Unit Weight: 2 mg
Input Voltage: 2.7 V to 6.5 V
Mounting Style: SMD/SMT
Output Current: 30 mA
Output Voltage: 2.7 V to 38 V
Development Kit: TPS61163AEVM-564
Number of Outputs: 2 Output
Number of Channels: 2 Channel
Input Voltage - Max: 6.5 V
Input Voltage - Min: 2.7 V
Operating Frequency: 1.2 MHz
Supply Current - Max: 2 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
