Function: Shift Register
Input Type: CMOS
Logic Type: CMOS
Output Type: 3-State
Logic Family: LV
Mounting Style: SMD/SMT
Number of Bits: 8 bit
Triggering Type: Positive-Edge
Counting Sequence: Serial to Serial/Parallel
Number of Circuits: 1 Circuit
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2 V
Propagation Delay Time: 22.5 ns, 16.5 ns, 10.2 ns
Low Level Output Current: 16 mA
Operating Supply Voltage: 2 V to 5.5 V
High Level Output Current: - 16 mA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
