Width: 3.91 mm
Height: 1.58 mm
Length: 8.65 mm
Function: NAND
Input Type: TTL
Logic Type: 3-Input NAND
Output Type: TTL
Unit Weight: 129.400 mg
Logic Family: F
Logic Function: NAND
Mounting Style: SMD/SMT
Number of Bits: 3 bit
Number of Gates: 3 Gate
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 4.5 V
Number of Input Lines: 9 Input
Number of Output Lines: 3 Output
Propagation Delay Time: 6 ns
Low Level Output Current: 20 mA
Operating Supply Current: 7.7 uA
Operating Supply Voltage: 5 V
High Level Output Current: - 1 mA
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: 0 C
