Width: 10.7 mm
Height: 4.5 mm
Length: 20.02 mm
Features: Adj Current Limit, Shutdown
Shutdown: Shutdown
Input Type: Rail-to-Rail
Supply Type: Single, Dual
Unit Weight: 5.838 g
Amplifier Type: High Output Current Amplifier
Mounting Style: Through Hole
SR - Slew Rate: 9 V/us
Voltage Gain dB: 110 dB
Number of Channels: 1 Channel
Dual Supply Voltage: +/- 5 V, +/- 9 V, +/- 12 V
Supply Voltage - Max: 60 V
Supply Voltage - Min: 8 V
Ib - Input Bias Current: 500 nA
Operating Supply Current: 26 mA
Operating Supply Voltage: 8 V to 60 V, +/- 4 V to +/- 30 V
Vcm - Common Mode Voltage: Negative Rail - 0.1 V to Positive Rail - 3 V
Output Current per Channel: 8 A
Vos - Input Offset Voltage: 5 mV
Maximum Dual Supply Voltage: +/- 30 V
Minimum Dual Supply Voltage: +/- 4 V
GBP - Gain Bandwidth Product: 900 kHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 1 pA/sqrt Hz
en - Input Voltage Noise Density: 70 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 95 dB
PSRR - Power Supply Rejection Ratio: 92.04 dB
