Shutdown: Shutdown
Topology: CMOS
Input Type: Rail to Rail
Technology: CMOS
Output Type: Rail to Rail
Settling Time: 0.5 us
Amplifier Type: Differential
Mounting Style: SMD/SMT
SR - Slew Rate: 30 V/us
THD plus Noise: 0.0001 %
Number of Channels: 2 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2.2 V
Ib - Input Bias Current: 0.2 pA
Operating Supply Current: 3.8 mA
Ios - Input Offset Current: 0.2 pA
Vos - Input Offset Voltage: 3 uV
Maximum Dual Supply Voltage: 2.75 V
Minimum Dual Supply Voltage: 1.1 V
GBP - Gain Bandwidth Product: 40 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 0.125 pA/sqrt Hz
en - Input Voltage Noise Density: 25 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 96 dB
