Width: 1.6 mm
Height: 1.02 mm
Length: 2.92 mm
Shutdown: No Shutdown
Input Type: Rail-to-Rail
Output Type: Rail-to-Rail
Supply Type: Single, Dual
Unit Weight: 6.300 mg
Mounting Style: SMD/SMT
SR - Slew Rate: 1.9 V/us
Voltage Gain dB: 100.83 dB
Number of Channels: 1 Channel
Dual Supply Voltage: +/- 3 V, +/- 5 V, +/- 9 V, +/- 12 V, +/- 15 V
Supply Voltage - Max: 32 V
Supply Voltage - Min: 2.7 V
Ib - Input Bias Current: 60 nA
Operating Supply Current: 600 uA
Operating Supply Voltage: 3 V, 5 V, 9 V, 12 V, 15 V, 18 V, 24 V, 28 V
Output Current per Channel: 12 mA
Vos - Input Offset Voltage: 4 mV
Maximum Dual Supply Voltage: +/- 16 V
Minimum Dual Supply Voltage: +/- 1.35 V
GBP - Gain Bandwidth Product: 4.6 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 0.26 pA/sqrt Hz
en - Input Voltage Noise Density: 31 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 106 dB
PSRR - Power Supply Rejection Ratio: 86 dB
