Width: 5.3 mm
Height: 1.95 mm
Length: 10.3 mm
Function: 8-Input NOR/OR Gate
Input Type: CMOS
Logic Type: 8-Input NOR/OR
Output Type: CMOS
Unit Weight: 208.300 mg
Logic Family: 4000
Logic Function: MUX Gates
Mounting Style: SMD/SMT
Number of Bits: 1 bit
Number of Gates: 1 Gate
Quiescent Current: 20 nA
Supply Voltage - Max: 18 V
Supply Voltage - Min: 3 V
Number of Input Lines: 8 Input
Number of Output Lines: 1 Output
Propagation Delay Time: 75 ns
Low Level Output Current: 6.8 mA
Operating Supply Current: 15 uA
Operating Supply Voltage: 10 V
High Level Output Current: - 6.8 mA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
