Width: 7 mm
Height: 1 mm
Length: 7 mm
Features: Oscillator
Input Type: Differential/Pseudo-Differential
Resolution: 16 bit
Unit Weight: 137.400 mg
Architecture: SAR
Sampling Rate: 4 MS/s
Interface Type: Parallel
Mounting Style: SMD/SMT
Reference Type: External, Internal
Development Kit: ADS8422EVM
Power Consumption: 155 mW
Reference Voltage: 4.75 V
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Number of Converters: 1 Converter
Supply Voltage - Max: 5.25 V
Supply Voltage - Min: 4.75 V
Analog Supply Voltage: 4.75 V to 5.25 V
Digital Supply Voltage: 2.7 V to 5.25 V
Operating Supply Voltage: 4.75 V to 5.25 V
INL - Integral Nonlinearity: +/- 2 LSB
SNR - Signal to Noise Ratio: 92 dB
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
DNL - Differential Nonlinearity: - 1 /1.5 LSB
SINAD - Signal to Noise and Distortion Ratio: 92.5 dB
