Shutdown: No Shutdown
Input Type: Differential
Resolution: 12 bit
Output Type: LVDS
Architecture: Folding Interpolating
Sampling Rate: 1.6 GS/s, 3.2 GS/s
Interface Type: Parallel LVDS
Mounting Style: SMD/SMT
Power Consumption: 4.4 W
Number of Channels: 1 Channel/2 Channel
Supply Voltage - Max: 2 V
Supply Voltage - Min: 1.8 V
Analog Supply Voltage: 1.8 V to 2 V
Digital Supply Voltage: 1.8 V to 2 V
INL - Integral Nonlinearity: +/- 2.5 LSB
SNR - Signal to Noise Ratio: 56.9 dBFS, 58.4 dBFS, 58.6 dBFS
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
DNL - Differential Nonlinearity: +/- 0.5 LSB
ENOB - Effective Number of Bits: 8.9 bit, 9.1 bit
THD - Total Harmonic Distortion: - 62 dBFS, - 62.3 dBFS, - 63.2 dBFS
SFDR - Spurious Free Dynamic Range: 61.7 dBFS, 62.1 dBFS, 63.3 dBFS
SINAD - Signal to Noise and Distortion Ratio: 55.5 dB, 56.5 dBFS, 56.6 dBFS
