TESTO 324 Professional pressure and air leak measuring device set

Temperature - NTC

Measuring range: -20 to +100°C

Temperature - TC Type K (NiCr-Ni)

Measuring range: -40 to +600 °C

Accuracy: ±0.5 °C or ±0.5 %

Absolute Pressure

Measuring range: 600 to 1150 hPa

Accuracy: ±3 hPa

Overload to 1200 hPa

Leakage measurement

Measuring range: 0 to 10 l/h

Accuracy: ±0.2 l/h or ±5 % of mv

Resolution: 10.0

Pressure measurement

Measuring range: 0 to 1000 hPa

Accuracy: ±0.5 hPa to ±3 % of mv

General technical data

Operating temperature: +5 to +40 °C

Protection class: IP40 acc. to EN 60529

Additional probe sockets: 2 Hirschmann sockets for connecting pressure and temperature probes

Gas connections: 2 pressure connections DN 5

DVGW permit according to 5925: Instrument class L up to volume = 200 litres

Storage temperature: -20 to +50 °C

Weight: 8500 g

Pipe volume calculation: max. 1200 ±0.2 or ±5 (1 to 200 l)
