Characterized frequency range: 200 kHz – 700 MHz
Directivity:
600 kHz – 700 MHz > 20 dB
10 MHz – 500 MHz > 30 dB
Coupling: 300 kHz – 700 MHz -30 dB ± 0.5 dB
Insertion loss:
200 kHz – 100 MHz < 0.7 dB
100 MHz – 700 MHz < 1.5 dB
Max. power:
200 kHz – 200 MHz 50 W CW *)
200 MHz – 700 MHz 40 W CW *)
*) Output shorted or open: max. 12.5 W
Operating temperature range: - 20 °C to + 40 °C
Impedance: 50 Ω
Port matching: > 20 dB
RF connectors, through ports: N-female
RF connectors, coupling ports: SMA-female
Dimensions: 113 mm x 60 mm x 35 mm
Weight: 290 g
