Characterized frequency range: 200 kHz – 500 MHz
Directivity:
200 kHz – 500 MHz > 20 dB
800 kHz – 50 MHz > 30 dB
Coupling:
200 kHz – 300 MHz -40 dB ± 0.3 dB
300 MHz – 500 MHz -40 dB ± 1 dB
Insertion loss:
200 kHz – 200 MHz < 0.3 dB
200 MHz – 500 MHz < 0.7 dB
Max. power:
200 kHz – 200 MHz 100 W CW *)
200 MHz – 500 MHz 70 W CW *)
*) Short time (max. 1 minute): 150 W Output shorted or open: max. 35 W
Operating temperature range: - 20 °C to + 40 °C
Impedance: 50 Ω
Port matching: > 20 dB
RF connectors, through ports: N-female
RF connectors, coupling ports: SMA-female
Dimensions: 113 mm x 60 mm x 35 mm
Weight: 290 g
