Maximum supply voltage: 5.5V
Maximum input power: +10 dBm
Input, Output: 50 Ohm, SMA female
Nominal supply Voltage: 5V, typ. 100mA, Mini-USB-B connector
1dB output compression point @ 100 MHz: +19.2 dBm typical
1dB output compression point @ 500 MHz: +19 dBm typical
1dB output compression point @ 1000 MHz: +18.3 dBm typical
3rd order output intercept point @ 100 MHz: +38dBm
3rd order output intercept point @ 500 MHz: +37dBm
3rd order output intercept point @ 1000 MHz: +33dBm
Reverse isolation S12: -28dB
Input matching: 30kHz-1.5GHz < - 16 dB
Output matching: 30kHz-1.5GHz < - 10 dB
Noise Figure: 2.7 dB
Gain:
30 kHz: 17.2 dB
150 kHz: 23.6 dB
1 MHz: 24.2 dB
100 MHz: 24 dB
500 MHz: 22.9 dB
1 GHz: 21.1 dB
1.5 GHz: 19.5 dB
3 GHz: 14.1 dB
6 GHz: 5.3 dB
