Frequency range: 9 kHz – 600 MHz
Attenuation: 10 dB – 0.5/+1.2 dB in-band (9 kHz to 600 MHz)
Attenuation HP-filter: > 30 dB @ 2kHz
Maximum continuous RF input power: 5W (+37 dBm) in-band
Maximum DC input voltage: ± 20V
Input matching, linear operating range: 9 kHz - 600 MHz < - 16 dB
Output matching, linear operating range: 9 kHz - 600 MHz < - 23 dB
Linear operating range: up to 0 dBm input level, in-band
Limiting threshold: +11 dBm (@ 37dBm input level)
Input connector: N-female
Output connector: N-male
Dimensions: 156 mm x 26 mm x 26mm
Weight: 170 g
