Input: 50 Ohm, SMA female
Output: 50 Ohm, SMA female
Nominal supply Voltage: 5V, typ. 225mA, Mini-USB-B connector
Maximum supply voltage: 5.5V
Maximum input power: +6dBm
1dB output compression point @ 40MHz: +21.5dBm
1dB output compression point @ 2 GHz: +22.5dBm
3rd order output intercept point @ 40 MHz: +39.8dBm
3rd order output intercept point @ 2 GHz: +42.8dBm
Reverse isolation S12: < -40dB
Noise Figure: 3.1 … 4.1 dB
Gain:
25 MHz: 26 dB
50 MHz: 28.4 dB
100 MHz: 28.6 dB
500 MHz: 28.6 dB
1 GHz: 28.8 dB
1.5 GHz: 28.3 dB
2 GHz: 27.2 dB
2.5 GHz: 28.5 dB
3 GHz: 28.9 dB
