Tekbox TBCS101-TGA DC-coupled driver amplifier (20dB, DC – 40 MHz)

General specification

Frequency range: DC – 40 MHz, 3 dB band width, typical

Gain: 20 dB, typ. ( ≙ linear voltage gain 10) with 50 Ohm load impedance

RF-connectors: BNC-female

Input specification

Input impedance: 50 Ω

Input return loss: > 30 dB, typ.

Maximum input level: -5 dBm ( ≙ 0.35 Vpp ); for output saturation

Maximum ratings: +20 dBm in a 50 Ohm system / ± 1.5V DC max. input rating

Output specification

Output impedance: 50 Ω

Output return loss: > 20 dB, typ.

P1dBout: +15 dBm ( ≙ 3.5 Vpp ); output saturation

IP3out : +25 dBm

DC offset: < 100mV at output; input terminated with 50 Ohm

Supply specification

Power-connector: USB-C

Indicator LEDs: Power ON

Operating voltage: 5 V DC

Current consumption: 90 mA

Operating temperature range: -20°C to +50°C

Dimensions: W 82 mm x H 33 mm x L 80 mm

Weight: 100 g
