Specified bandwidth: 1.5 GHz
Flatness of the comb spectrum: 8 dB typically
Output impedance: 50 Ohm
Output power: 66 dBµV @ 10 MHz f comb ; decreasing 6 dB with every fcomb/2
Amplitude stability: < 0.2 dB; <0.1 dB after 15 minutes
Aging: < 0.5 dB over 12 months
Output connector: N-female
Selectable, fixed comb frequencies: 100 kHz, 500 kHz, 1 MHz, 5 MHz, 10 MHz
Frequency stability: 50 ppm
External excitation input: 5 kHz – 300 MHz @ square input signal; 3.3 Vpp max 100 kHz – 300 MHz @ sinus input signal; 3.3 Vpp max
Input impedance: 50 Ohm
Input connector: SMA-female
Current consumption: 70 mA
Indicators: Power On LED, Low Battery LED
Power supply: 4 x AA NiMH (e.g. Varta Mignon 2700, not supplied)
Charger: external; Ansmann ACS110
Operation time: battery capacity / 70 mA
Temperature range: -20°C to +45 °C
Housing diameter: 180 mm
Housing height: 60 mm
Weight: 1250 g
