Electrical Specifications
Number of Channels: 1
Input Impedance: 50 Ω Direct Coupled
Output Voltage Range: 0 to ± 25 V Direct Coupled
Maximum Output Current: 750 mA
Sine Wave Distortion (THD): See Figure 2 (datasheet)
Voltage Gain: +10 Fixed
Bandwidth: DC to 2 MHz, 50 Vp-p Full Load (-3 dB)
Full Power Bandwidth: DC to 500 kHz / 50 Vp-p / 750 mA Sine - Typical (-0.4 dB) (RL=33 Ω)
Slew Rate: >200 V/μs
Square Wave Response (10 %-90 %):
< 0.16 μs for 35 Volt Step
RL=23 Ω - Typical
Aberrations:
< 2 %
50 Ω Voltage Monitor Output 50 Ω Input Z (20:1 Ratio)
> 1 MΩ Input Z (10:1 Ratio)
Environmental
Operating Temperature: 0 ºC to +45 ºC (+32 ºF to +113 ºF) Ambient
Storage Temperature: -20 ºC to +50 ºC (-4 ºF to +122 ºF)
Humidity Range: < 80 % RH Non-Condensing
General
Input Supply Voltage: 110/220 50/60 Hz – Rear Panel Selectable
Power Rating: 100 VA; 80 W
Dimensions (H x W x L): 4.51 in x 10.14 in x 11.81 in (11.5 x 25.8 x 30.0 cm)
Weight (approximate): 4.5 kg (10 lb)
Recommended Calibration Cycle: 1 Year
Warranty: 1 Year Parts and Labor
Included Accessories:
CD User’s Manual - P/N 810049-CD
Power Cord - P/N 60014
