Width: 60 mm (2.362 in)
Height: 32 mm (1.26 in)
Length: 93.5 mm (3.681 in)
Approvals: CSA60950-1, DENAN, EN60950-1, EN50178(OV II), UL60950-1
Compliance: CSA60950-1, DENAN, EN60950-1, EN50178(OV II), UL60950-1
Efficiency: 85 %
Output Power: 12 W
REACH - SVHC: Details
Input Voltage: 85 VAC to 265 VAC, 120 VDC to 370 VDC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 500 mA
Output Voltage-Channel 1: 24 VDC
Operating Temperature Range: - 10 C to + 60 C
Maximum Operating Temperature: + 60 C
Minimum Operating Temperature: - 10 C
