TDK-Lambda CN50B110-24 Isolated Technical Resources

Width: 37.2 mm (1.465 in)

Height: 12.7 mm (0.5 in)

Length: 58.3 mm (2.295 in)

Industry: Industrial

Dimensions: 58.3 mm x 37.2 mm x 12.7 mm

Output Power: 50 W

Input Voltage: 43 VDC to 160 VDC

Mounting Style: Through Hole

Isolation Voltage: 3 kV

Number of Outputs: 1 Output

Input Voltage - Max: 160 V

Input Voltage - Min: 43 V

Input Voltage, Nominal: 110 V

Output Current-Channel 1: 2.1 A

Output Voltage-Channel 1: 24 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
