TDK InvenSense ICS-41351 Multi Mode Top Port PDM Low-Power Multi-Mode Microphone with High AOP Mode

Depth: 0.98 mm

Shape: Rectangular

Width: 2.65 mm

Length: 3.5 mm

Port Type: Top

Dimensions: 3.5 mm x 2.65 mm x 0.98 mm

Technology: MEMS

Output Type: Digital

Sensitivity: - 26 dB

Unit Weight: 340.595 mg

Mounting Style: SMD/SMT

Frequency Range: 1 MHz to 2.65 MHz

Termination Style: SMD/SMT

Sound Pressure Level: 160 dB

Supply Voltage - Max: 3.63 V

Supply Voltage - Min: 1.65 V

Operating Supply Current: 600 uA

Operating Supply Voltage: 1.65 V to 3.63 V

SNR - Signal to Noise Ratio: 65 dBA

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
