Gain: 1.49 dbi, 0.92 dBi, 1.76 dBi, 1.35 dBi, 2.4 dBi, 2.53 dBi, 2.38 dBi, 2.3 dBi, 2.46 dBi, 2.69 dBi, 4.62 dBi
VSWR: 3:1
Style: Ceramic
Width: 6 mm
Height: 6 mm
Length: 35 mm
Impedance: 50 Ohms
Technology: Cellular 2G/3G
Application: Cellular Application
Unit Weight: 3 g
Polarization: Linear
Power Rating: 5 W
Mounting Style: PCB Mount
Electrical Type: PIFA
Number of Bands: 6 Band
Center Frequency: 800 MHz, 850 MHz, 900 MHz, 1700 MHz, 1800 MHz, 1900 MHz, 2100 MHz
Mechanical Style: Chip
Maximum Frequency: 2.2 GHz
Minimum Frequency: 800 MHz
Moisture Sensitive: Yes
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
