Gain: 28 dBi, 28 dBi, 28 dBi
VSWR: 3:1, 2:1, 3
Style: Panel
Width: 134 mm
Height: 20 mm
Length: 146 mm
IP Rating: IP67
Impedance: 50 Ohms
Cable Type: KSR-200P, RG-174
Application: GNSS, LTE, WiFi
Cable Length: 3 m
Polarization: Linear, RHCP
Mounting Style: Bracket Mount
Electrical Type: MIMO
Number of Bands: 6 Band
Center Frequency: 1.57542 GHz, 1.602 GHz, 1.561098 GHz
Mechanical Style: Module
Maximum Frequency: 5.85 GHz
Minimum Frequency: 698 MHz
Termination Style: RP-SMA Male, SMA Male
Antenna Connector Type: RP-SMA Male, SMA Male
Protocol - GPS, GLONASS: GNSS
Protocol - WiFi - 802.11: WiFi
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE)
