Gain: 3.5 dBi, 1.6 dBi
VSWR: 3:1, 3:1
Style: Dome
Length: 19.6 mm
Diameter: 55.23 mm
IP Rating: IP67, IP69K
Impedance: 50 Ohms
Cable Type: RG174 x 2
Technology: 2.4/5GHz Dual Band MiMo
Application: Remote Monitoring, Smart Meter Systems, Construction Equipment, Public Safety
Unit Weight: 60 g
Cable Length: 1 m
Polarization: Linear
Power Rating: 5 W
Mounting Style: Direct / Permanent Mount
Electrical Type: MIMO
Number of Bands: 2 Band
Center Frequency: 2.45 GHz, 5.5 GHz
Mechanical Style: Module
Maximum Frequency: 5.85 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: RP-SMA Male
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
