Taoglas FW.90.SMA.M Passive Antenna Meteor FW.90 4G/3G/2G Cellular Flexible Whip, SMA(M)

Gain: - 1.7 dBi, 2 dBi, 4.7 dBi, 5.1 dBi, 4.6 dBi, 4.7 dBi, 4.3 dBi

Style: Straight

Length: 255 mm

Diameter: 16 mm

IP Rating: IP65

Impedance: 50 Ohms

Technology: Penta Band Cellular

Application: Smart Metering, Remote Pipeline Monitor, Transportation

Unit Weight: 60 g

Polarization: Linear

Power Rating: 50 W

REACH - SVHC: Details

Mounting Style: Panel Mount

Electrical Type: Monopole

Number of Bands: 7 Band

Center Frequency: 700 MHz, 800 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2600 MHz, 3400 MHz

Mechanical Style: Whip

Maximum Frequency: 3.5 GHz

Minimum Frequency: 698 MHz

Termination Style: Connector

Antenna Connector Type: SMA Male

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, GPRS, WCDMA
