Symbologies: 1-dimensional codes: Code 39, Code 128, Code 93, ITF 25, CodaBar, EAN 8, EAN 13, UPCA, UPCE, ITF 14 2-dimensional codes: QR Code, Data Matrix
Max. frame rate: 20 fps
Max. reading speed: 60 codes/sec
Sensor type: CMOS, rolling shutter
Pixel size: 2.4 µm × 2.4 µm
Sensor size: 1 inch
Resolution: 5440 × 3648
Exposure time: 16 μs to 0.5 sec
Gain: 0 dB to 40 dB
Mono/color: Mono
Communication protocol: SmartSDK, TCP Client, TCP Server, Serial, FTP
Data interface: GigE
Digital I/O: 12-pin M12 connector provides power and I/O, including opto-isolated input (LineIn 0/1/2) × 3, opto-isolated output (LineOut 3/4/5) × 3, and RS-232 × 1.
Power supply: 12 VDC to 24 VDC
Max. power consumption: 12 W@24 VDC
Lens mount: C-mount
Light source: Not included
Lens cap: Included
Dimension: 126 mm × 66 mm × 113.2 mm
Weight: Approx. 750 g (1.7 lb.)
Ingress protection: IP67 ( under proper installation of waterproof lens cap)
Temperature: Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: -30 °C to 70 °C (-22 °F to 158 °F)
Humidity: 20% to 95% RH, non-condensing
Client software: IDMVS
Certification: CE, RoHS
