Transmitter (TX):
Output frequency: 82,175 kHz ±0.02%
Output power: 1 watt maximum
Operating Modes: Direct connection mode, Inductive mode, External coil mode (optional)
Battery type: Six Alkaline LR20 "D"
Battery life:
Direct mode: 50 hours (Output 4 mA, 20°C/68°F)
Full power (1W): 20 hours (20°C/68°F)
Battery Status: Low battery indication
Audio Indication: Internal Speaker: Alarm, Beeping sounds
Output Temperature: -20°C to 50°C / -4°F to 122°F
Dimensions: (H)244 mm x (W)220 mm x (D)92 mm (9.61" x 8.66" x 3.62")
Weight: 2.6 kg / 5.8 lbs. approx. Including eight batteries
Protection: IP54 (Protection from splashed water)
Receiver (RX):
Output frequency: 82.175 kHz ±20Hz
Battery type: Four Alkaline LR6 "AA"
Battery life: 30 hours (20°C/68°F, speaker sound off, backlight off)
Battery Status: Continuous indication
Power save function: Automatically power off after 30 minutes of inactivity
Visual Indication: LCD Bar graph, digital number & character, include backlight
Depth Display Range: 0 to 5 m/16 ft. Depth readout unit: meter / feet & inch
Current value: Current value flowing on the conductor is displayed for line identification in malliamps
Audio output: Internal Speaker with volume adjustment
Operating Temperature: -20°C to 50°C / -4°F to 122°F
Dimensions: (H)661 x (W)228 x (D)195 mm (26.0" x 8.98" x 7.68")
Weight: 1.1 kg/2.4 lbs. approx. including four batteries
Protection grade: IP54 (Protection from splashed water)
