Temperature range (*1): -10℃ to +80℃
Ambient temperature range: +5℃ to +35℃
Control accuracy (*2): ±0.5℃, Heater PID control
Compressor output, Refrigerant: 150W, R134a
Cooling capacity (at 50Hz) (*3): approx. 0.29kW
Heater output: 0.6kW
Temperature setting display: Digital system (setting/display switching system)
Safety device/function: Short/Over current breaker, Alarm and warning for compressor, High and Low temperature, Alarm and warning for pump motor, Abnormal temperature sensor diagnosing circuits, Alarm for replenishing liquid, Lowwater cut off, Phase-reversal relay
Other Functions: Temperature check monitor, Remote temperature setting, Safety signal for safety devise, External temperature sensor connection
Water bath capacity (water level 80%) (*4): approx. 14L
Applicable pump unit: Contact us
Dimensions (Pump unit is not included): 407×485×676H mm
Weight (Pump unit not included): approx. 46kg
Power Supply (Pump unit is not included): AC100V/15A MAX20A (Need a step-down transformer)
Operation current (Pump unit is not included): 10A
Standard accessories: Power cord, Drain hose × 1 pc, Connector for signal × 1 pc
Catalog
(*1)When setting below +7℃, please be sure to use antifreeze (Please ask us for details). The compressor is stopped when the circulating fluid temperature is above 40℃.
(*2)Performance may not be maintained due to the heating medium, environmental temperature, heat load, circulation pipe distance, etc.
(*3)Capacity when using tap water and the circulating fluid temperature at 10℃. The capacity varies with the pump unit mounted. The capacity decreases when the ambient temperature is above +30℃.
(*4)Due to the structure not being sealed, the circulating fluid may evaporate and reduce depending on the set temperature and heating medium type.
