Frequency
Range
Sine: 1μHz ~ 20MHz
Square, Pulse: 1μHz ~ 5MHz
Others: 1μHz ~ 1MHz
Resolution: 1μHz, 6 digits
Accuracy: ±20ppm
Waveform
Type: 11 build-in waveform(Sine, Square, Ramp, Pulse, etc.) +5 user-defined arbitrary waveforms
Length: 4096 points
Sampling Rate: 100 MSa/s
Vertical Resolution: 10 bits
Amplitude
Range
Frequency ≤8MHz: 0 ~ 10Vpp(50Ω), 0 ~ 20Vpp (Open circuit)
Frequency> 8MHz: 0 ~ 9 Vpp(50Ω), 0 ~ 18Vpp (Open circuit)
Resolution
2mVpp (Amplitude>2Vpp)
0.2mVpp (Amplitude≤2Vpp)
Offset (Ampl. 0Vpp)
Range: ±5Vdc (50Ω), ±10Vdc (Open circuit)
Resolution: 2mVdc
Modulation (CHA)
FM,AM,PM,PWM
Carrier Waveform: 16 waveforms, Sine, Square, Ramp, etc. (only Pulse for PWM)
Modulating Waveform: 16 waveforms, Sine, Square, Ramp, etc.
Modulating Frequency: 2mHz ~ 20kHz
FSK
Carrier Waveform: 16 waveforms, Sine, Square, Ramp, etc.
Hope Frequency: 1μHz ~ 20MHz
Rate: 1mHz ~ 100kHz
Sweep (CHA)
Carrier Waveform: 16 waveforms, Sine, Square, Ramp, etc.
Type: Linear or Logarithmic
Sweep Time: 50ms ~ 500s
Burst (CHA)
Carrier Waveform: 16 waveforms, Sine, Square, Ramp, etc.
Burst Count: 1 ~ 1000000
Internal Period: 1μs ~ 500s
Start/Stop Phase: 0° ~ 360°
SYNC Output
Waveform Characteristic: Square, rise/fall time ≤ 20ns
Output Level: TTL compatible
Counter
Frequency Range: 1Hz ~ 100MHz
Input Amplitude: 100mVrms ~ 7Vrms
Period: 50ms ~ 5s
General Characteristics
Power: AC 100 ~ 240V, 45 ~ 65Hz, < 30VA
Display: VFD display
Dimension & Weight: 322×256×102mm, Approx.1.5 kg
Standard Accessories
Power Cord: 1pcs
CD(Software+ User's Guide): 1pcs
Features
* Dual channel outputs
* Frequency accuracy 20ppm and 1μHz resolution
* Abundant modulation function AM, FM, PM,
PWM and FSK
* Provide sweep and burst
* 100MHz Built-in counter
* Standard interface: USB Host & Device
