Measuring Functions
Frequency Range
CH 1: 0.001Hz ~ 200MHz
CH 2: 0.001Hz ~ 200MHz
CH 3: options 3GHz/6.5GHz/12.4GHz/16GHz/20GHz/26.5GHz/40GHz
Display Resolution: 11 digits/s
Period: 5ns ~ 1000s
Time Interval Range: 1ns ~ 10000s
Time Resolution: 150ps
Pulse Width: 1ns ~ 10000s
Duty Cycle: 1% ~ 99%
Totalize: 0 ~ 1×10^13
Phase Difference: 1° ~ 359°
Input
Dynamic Range: 50mVrms ~ 1.0Vrms (Sine), 150mVPP ~ 4.5VPP(Pulse)
Input Impedance: 1MΩ//35pF or 50Ω
Input Attenuation: ×1 or ×10
Trigger Level: -5.000V ~ +5.000V
Other Functions
Frequency Ratio √
Up/Low Limit: "Limit" light on shows the result out of range, off shows within range
Statistics Calculation: Multi-average, Max.,Min., PPM, SD, Allan Variance
Standard Time Base
Accuracy: 5×10^-8
Daily Aging: 1×10^-8/day
Optional Time Base
Accuracy: 5×10^-8
Daily Aging: 5×10^-10/day
General Characteristics
Interface: USB , RS-232
Optional: GPIB
Power: AC220V (1 ±10%), 50Hz(1±5%)<70VA
Dimension & Weight: 375×105×235mm, 4.2kg
