Shutdown: Shutdown
Input Type: Rail-to-Rail
Output Type: Rail-to-Rail
Unit Weight: 80 mg
Qualification: AEC-Q100
Mounting Style: SMD/SMT
SR - Slew Rate: 13 V/us
Number of Channels: 2 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2 V
Ib - Input Bias Current: 2 pA
Operating Supply Current: 1.9 mA
Vcm - Common Mode Voltage: 5.6 V
Ios - Input Offset Current: 2 pA
Output Current per Channel: 65 mA
Vos - Input Offset Voltage: 200 uV
GBP - Gain Bandwidth Product: 20 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 7 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 120 dB
PSRR - Power Supply Rejection Ratio: 110 dB
