STMicroelectronics TSC2012IST Current Sense Amplifiers High volt, precision, bidirectional current sense amplifier

Accuracy: 0.1 %

Gain V/V: 100 V/V

Shutdown: Shutdown

Gain Error: 0.3 %

Unit Weight: 28 mg

3 dB Bandwidth: 415 kHz, 490 kHz

Amplifier Type: Precision Bidirectional Amplifier

Mounting Style: SMD/SMT

SR - Slew Rate: 2.8 V/us, 5.2 V/us

Number of Channels: 1 Channel

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 2.7 V

Ib - Input Bias Current: 350 uA

Operating Supply Current: 2.3 mA, 2.45 mA

Vcm - Common Mode Voltage: - 20 V to 70 V

Vos - Input Offset Voltage: 1.1 mV

GBP - Gain Bandwidth Product: 415 kHz

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C

en - Input Voltage Noise Density: 100 nV/sqrt Hz

CMRR - Common Mode Rejection Ratio: 120 dB

PSRR - Power Supply Rejection Ratio: 100 dB
