STMicroelectronics MP23ABS1TR MEMS Audio Sensor High performance MEMS audio sensor single ended analog bottom-port microphone

Depth: 0.98 mm

Shape: Rectangular

Width: 2.65 mm

Length: 3.5 mm

Port Type: Bottom

Tolerance: 1 dB

Output Type: Analog

Sensitivity: - 38 dB

Unit Weight: 21 mg

Mounting Style: SMD/SMT

Frequency Range: 10 Hz to 10 kHz

Termination Style: SMD/SMT

Moisture Sensitive: Yes

Sound Pressure Level: 130 dB

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 1.52 V

Directional Properties: Omnidirectional

Operating Supply Current: 120 uA

Operating Supply Voltage: 2.75 V

SNR - Signal to Noise Ratio: 64 dB

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
